Peter Paul Solenoid Valve Model H22

GAS PRESSURE RATINGSORIFICE SIZECV FACTORVALVE NUMBERACDCGROMMET HOUSINGCONDUIT HOUSING1/8″ NPT PORTS1/4″ NPT PORTS1/8″ NPT PORTS1/4″ NPT PORTS5000*5000*.025.010H22M7DGMH22M9DGMH22M7DCMH22M9DCM3000*3000*1/32.022H22G7DGM H22G9DGMH22G7DCMH22G9DCM2500*1500*3/64.041H22H7DGMGH22H9DGMGH22H7DCMGH22H9DCMG1750*5001/16.065H22J7DGMGH22J9DGMGH22J7DCMGH22J9DCMG650*1003/32.100H22K7DGMGH22K9DGMGH22K7DCMGH22K9DCMG LIQUID PRESSURE RATINGSORIFICE SIZECV FACTORVALVE NUMBERACDCGROMMET HOUSINGCONDUIT HOUSING1/8″ NPT PORTS1/4″ NPT PORTS1/8″ NPT PORTS1/4″ NPT PORTS5000*5000*.025.010H22M7DGMH22M9DGMH22M7DCMH22M9DCM3000*3000*1/32.022H22G7DGMH22G9DGMH22G7DCMH22G9DCM1500*1500*3/64.041H22H7DGMLH22H9DGMLH22H7DCMLH22H9DCML1000*5001/16.065H22J7DGMLH22J9DGMLH22J7DCMLH22J9DCML3001003/32.100H22K7DGMLH22K9DGMLH22K7DCMLH22K9DCML* FKM seals not recommended for pressure above 500 psi.Ordering Information:When ordering valves or repair packs add voltage and frequency to complete valve number. for examples: valve (H22J7DGMG 120/60) repair pack (KH22JD AC)When ordering operators add the letter “O” to the front of the valve number, replace body port number with the letter “D”: example: operator (OH22JDDGMG 120/60) Operating Conditions:Media: Air and other non-corrosive gasses, water and oil.Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) media.Optional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 10,000 PSILeakage: Bubbletight (with polymer sealing pins) Electrical Characteristics:Coil Voltage: 12/DC, 24/DC, 48/DC, 125/DC, 120/60-110/50, 240/60, and 24/60.Nominal Power: AC — 7.7 Watts DC — 9.5 WattsCoil Construction: Molded (Std.), Non-molded Class A and Potted Class F or Class H (Opt.)Typical Response Time on Air:  4 – 16 MillisecondsOperating Speed:  Up to 600 CPMDuty Cycle:  Continuous Mechanical CharacteristicsBody: Stainless SteelInternal Components: Stainless Steel. Copper – AC Only.Elastomers: Nitrile (Buna) (Std.). Many other elastomers available.*Sealing Pin: Kel-F (Std.)Orifice Diameter: See table above.Porting: 1/8″ and 1/4″ NPT (other ports avaialble).Housing: Grommet and 1/2″ NPT conduit – many options available.*Mounting: Must be mounted within 30° of vertical.Life Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: Grommet Valve: 1.13 lbs, Conduit Valve: 1.19 lbsRepair Packs: See table above.Options: Alternate Port Locations, Alternate Elastomers, Alternate Sealing Pin Materials, Spade Terminal Coil, and European Style DIN Coil* * Consult us for options and specifications
