Peter Paul Magnetic Latching Valve Model MLV 152

MAX OPER PRESS. DIFFORIFICE SIZECV FACTORVALVE NUMBERDCLEADED COILDIN COIL5001/32.022152G2DGLM152G2DELM2503/64.055152H2DGLM152H2DELM1601/16.075152J2DGLM152J2DELM1003/32.130152K2DGLM152K2DELM501/8.230152N2DGLM152N2DELM Operating Conditions:Media: Air and other fluids compatible with standard Buna seals. Hot water, steam, gasoline, oils, some hydraulic fluids, and many other media require special seal materials. (Series 20 pressure ratings may change due to the viscosity of the liquid.)*Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) mediaOptional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 5,000 PSILeakage: Bubbletight (with polymer sealing pins)Vacuum:  To 5 Microns* Electrical Characteristics:Coil Voltage: 12, 24/DCNominal Power: DC — 10.5 WattsCoil Construction: Molded Class F. (155 C°)Typical Response Time on Air: Approximate 50 millisecond pulse to energize and de-energize.Operating Speed:  Up to 600 CPM Mechanical CharacteristicsBody: Stainless Steel (Std.) or Brass (Opt.)Internal Components: Stainless SteelElastomers: Nitrile (Buna) (Std.). Many other elastomers available.*Sealing Pin: See table above.Orifice Diameter: 1/8″ NPT (Std.)Life Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: 0.27 lb to 0.30 lb depending on model and housing style.Repair Packs: See table above.Options: Round Brass or Stainless Steel Body, Stackable Construction and Alternate Elastomers.* Consult us for options and specifications
