Peter Paul Magnetic Latching Valve Model MLV 25

MAX OPER PRESS. DIFFORIFICE SIZECV FACTORVALVE NUMBERDCN.C.N.O.N.C.N.O.DIN COILLEADED COIL1/8″ NPT PORTS1/4″ NPT PORTS1/8″ NPT PORTS1/4″ NPT PORTS5001/321/32.024.02425GG7XELM25GG9ZELM25GG7XGLM25GG9ZGLM2353/643/64.052.05225HH7XELM25HH9ZELM25HH7XGLM25HH9ZGLM2001/163/64.095.05225JH7XELM25JH9ZELM25JH7XGLM25JH9ZGLM1501/161/16.095.09525JJ7XELM25JJ9ZELM25JJ7XGLM25JJ9ZGLM1003/323/32.156.15625KK7XELM25KK9ZELM25KK7XGLM25KK9ZGLM1001/83/32.214.15625NK7XELM25NK9ZELM25NK7XGLM25NK9ZGLM Operating Conditions:Media: Air and other fluids compatible with standard Buna seals. Hot water, steam, gasoline, oils, some hydraulic fluids, and many other media require special seal materials. (Series 20 pressure ratings may change due to the viscosity of the liquid.)*Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) mediaOptional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 5,000 PSILeakage: Bubbletight (with polymer sealing pins)Vacuum:  To 5 Microns* Electrical Characteristics:Coil Voltage: 12, 24/DCNominal Power: DC — 10.0 WattsCoil Construction: Molded Class B with DIN 43650 Form A Connector (Std.), Leadwires (Opt.) For your convenience we have the female DIN style mating connector No. 20-198** available for an additional fee.*Typical Response Time on Air: Approximate 50 millisecond pulse to energize and de-energize.Operating Speed:  Up to 600 CPM Mechanical CharacteristicsBody: Stainless Steel (Std.) or Brass (Opt.)Internal Components: Stainless SteelElastomers: Nitrile (Buna) standard. FKM, EPDM, Neoprene and Low Temp Nitrile (Buna) are available.*Orifice Diameter: See table abovePorting: Standard 1/8” and 1/4” NPT (other ports available).*Life Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: 1.2 lb averageRepair Packs: See table above.Options: Alternate Port Locations, Metering and Alternate Elastomers** Consult us for options and specifications
