Peter Paul Magnetic Latching Valve Model MLV 26

MAX OPER PRESS. DIFFORIFICE SIZECV FACTORVALVE NUMBERDCN.C.N.O.N.C.N.O.DIN COILLEADED COIL1/8″ NPT PORTS1/4″ NPT PORTS1/8″ NPT PORTS1/4″ NPT PORTS4001/321/32.024.02426GG7XELM26GG9ZELM26GG7XGLM26GG9ZGLM1503/643/64.052.05226HH7XELM26HH9ZELM26HH7XGLM26HH9ZGLM1001/161/16.095.09526JJ7XELM26JJ9ZELM26JJ7XGLM26JJ9ZGLM753/323/32.156.15626KK7XELM26KK9ZELM26KK7XGLM26KK9ZGLM  Operating Conditions:Media: Air, water, and other fluids are compatible with standard Buna seals. Hot water, steam, gasoline, and many oils require other seal materials. (Series 20 pressure ratings may change due to the viscosity of the liquid.)*Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) media.Optional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 5,000 PSILeakage: Bubbletight (with polymer sealing pins)Vacuum:  To 5 Microns* Electrical Characteristics:Coil Voltage: 12, 24/DCNominal Power: DC — 10.0 WattsCoil Construction: Molded Class B with DIN 43650 Form A Connector (Std.), Leadwires (Opt.) For your convenience we have the female DIN style mating connector No. 20-198** available for an additional fee.*Typical Response Time on Air: Approximate 50 millisecond pulse to energize and de-energize.Operating Speed:  Up to 600 CPM Mechanical CharacteristicsBody: Stainless Steel (Std.) or Brass (Opt.)Internal Components: Stainless SteelElastomers: Nitrile (Buna) (Std.). Many other elastomers available.*Orifice Diameter: See table abovePorting:Standard 1/8” and 1/4” NPT (other ports available).*Life Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: 1.2 lb averageRepair Packs: See table above.Options: Alternate Port Locations, Metering and Alternate Elastomers** Consult us for options and specifications
