Peter Paul High Pressure Valve Model H24

MAX OPERATING PRESS. DIFF.ORIFICE SIZECV FACTORVALVE NUMBERDCINLETEXHINLETEXHGROMMET HOUSINGCONDUIT HOUSING1/8″ NPT PORTS1/4″ NPT PORTS1/8″ NPT PORTS1/4″ NPT PORTS1000*0.6 mm1/32.010.022H24MG7XGMH24MG9ZGMH24MG7XCMH24MG9ZCM* FKM seals not recommended for pressure above 500 psi. Ordering Information:When ordering valves or repair packs add voltage and frequency to complete valve number. for examples: valve (H24MG7XGM 120/60) repair pack (KH24MGX AC)When ordering operators add the letter “O” to the front of the valve number, replace body port number with the letter “D”: example: operator (OH24MGDDGM 120/60) Operating Conditions:Media: Air and other non-corrosive gases, water and oil.Filtration: Down to 60 microns or less is recommended.Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) mediaOptional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 10,000 PSILeakage: Bubbletight (with polymer sealing pins) Electrical Characteristics:Coil Voltage: 6, 12, 24, 125/DCNominal Power: DC — 9.5 WattsCoil Construction: Molded Class F (Std.), Potted and Class H OptionTypical Response Time on Air:  4 – 16 MillisecondsOperating Speed:  Up to 600 CPMDuty Cycle:  Continuous Mechanical CharacteristicsBody: Stainless Steel (Std.)Internal Components: Stainless SteelElastomers: Nitrile (Buna) (Std.). Many other elastomers available.*Sealing Pin: Kel-F (Std.)Orifice Diameter: See table above.Porting: 1/8″ and 1/4″ NPT (other ports available).*Housing: Grommet and 1/2″ NPT conduit – many options available.Mounting: Must be mounted within 30° of vertical.Life Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: 1.17 lbsRepair Packs: See table above.Options: Alternate Port Locations, Alternate Elastomers, Alternate Sealing Pin Materials, Spade Terminal Coil, and European Style DIN Coil** Consult us for options and specifications
