Peter Paul Magnetic Latching Valve Model MLV828 (IP)

MAX OPER PRESS. DIFFMIN OPER PRESS. DIFFORIFICE SIZECV FACTORPIPE SIZEVALVE NUMBERDCLEADED COILDIN COIL20031/24.01/2 NPT828B12DGLM828B12DELM20033/45.83/4 NPT828Y19DGLM828Y19DELM2003113.01 NPT828D13DGLM828D13DELM20031 1/229.01 1/2 NPT828E14DGLM828E14DELM2003246.02 NPT828F16DGLM828F16DELM2003376.02 1/2 NPT828W17DGLM828W17DELM2003398.03 NPT828W18DGLM828W18DELM Operating Conditions:Media: Air, water, and other fluids are compatible with standard Buna seals. Hot water, steam, gasoline, and many oils require other seal materials. (Series 20 pressure ratings may change due to the viscosity of the liquid.)*Valve Temperature Range:Standard Valves – 0°F (-18°C) to 104°F (40°C) ambient; 0°F (-18°C) to 150°F (65°C) media.Optional Valves – can tolerate much higher or much lower ambient and media temperatures.*Maximum Operating Pressure Differentials: See table above.Burst Pressure: 5,000 PSILeakage: Bubbletight (with polymer sealing pins)Vacuum:  To 5 Microns* Electrical Characteristics:Coil Voltage: 12, 24/DCNominal Power: DC — 10.0 WattsCoil Construction: MoldedTypical Response Time on Air: Approximate 50 millisecond pulse to energize and de-energize.Operating Speed:  Up to 100 CPM Mechanical CharacteristicsBody: Stainless SteelInternal Components: Stainless Steel (Std.)Elastomers: Nitrile (Buna) (Std.). Many other elastomers available.*Orifice Diameter: See table aboveLife Expectancy: Millions of cycles, depending on application, lubrication, etc.Valve Weight: 1.2 lb averageOptions: Alternate Elastomers* Consult us for options and specifications
